oem part numbers


i'm going to do my best to keep this updated. i'm compiling a list of the most common stock part numbers that people might need.

mazdaspeed accessories
mazdaspeed3 coilovers - RAMS8ML10
mazdaspeed3 springs with 2 rear camber links - GRMS8ML25
mazdaspeed3 rear camber links - GRMS8ML07
mazdaspeed3 cold air intake - GRMS8ML29 - who knows if they sell this?
mazdaspeed3 cai filter - GRMS8ML10
mazdaspeed3 exhaust - GRMS8ML26
mazdaspeed6 springs - GRMS8MH14
mazdaspeed6 cold air intake - GRMS8MH32 - who knows if they sell this?

maintenance
regular filter with o rings - L321143029U
spin on conversion - L31114311 and gasket - LF0114342
spin on filter - LF0514302A
drain plug washer - 995641400 - this normally comes with the filter
filter wrench - AKS75140
spark plugs - 000018L3Y3
drive belt - L3K915909A9U
radiator thermostat - L33615170
ignition coil - L3G218100A9U

Lighting
OEM HID ballast/control module for 3, CX7, CX9 - D530510H3

exterior
front bumper mustache - BA6R50B31A - to remove the holes left from your front plate bracket
undertray aka lower shield - BP4K56111L
undertray fasteners/clip-nuts (sides, need 4) - BAY6-56-496 or BR5S-56-496
undertray fasteners/clip-nuts (front, need 3) - FB01-50-133C
undertray bolts (7 total) - 90720-0620 (old) or 90720-0616 (new, shorter bolt)
skid plate, radiator support, the piece that is on the bottom in the front of the vehicle - BP4K56112
mazdaspeed3 wheels - 9965097080
mazdaspeed6 wheels - 9965117080
forged mazdaspeed wheels - BLMS8MZ01
center caps - G22C37190A

interior
coin holder - G22C55225
shift knob - GP9A46030B

under the hood
cylinder block - L3K910300H
valve cover - L3M610210A
mazdaspeed3 battery box tray - B37F56040D
mazdaspeed3 battery box and ecu cover - L33X18593B
mazdsapeed3 battery box front panel - L33X18591A
tmic cover - L3K9207B0F
oem egr tube - L3K920310A
oem egr valve - L3K920300
maf - L3K913215
map - L3K918211A
pcv - L3K913890
primary o2 - L33X188G1C
secondary o2 - L34B18861A
boost solenoid - L3K918741
ambient temp sensor - G51861764
knock sensor - L80718921
crankshaft position sensor - L3K918221A
mazdaspeed oil cap - BLMS8ML02
oem fuel pump - L3K91335ZC
oem boost tube from turbo to intercooler - L33L13760B
mazdaspeed3 (fits 2007 ms6) oem boost tube from intercooler to throttle body - L33X13770A
mazdaspeed3 oem cold pipe - L33X13241A
2006 mazdaspeed6 oem cold pipe - L3K913241B
2007 mazdaspeed6 oem cold pipe - L3K913241A
turbo oil drain/return line - L33E14290
gasket for top - L3K914293
gasket for bottom - L3K914264
bolts for previous two items - 9XF002127L
tensioner pulley - LF1715980E
OEM cam follower or "collar" - L3K9-12-615

brakes
mazdaspeed3 caliper bracket bolt - 9YA02A225
mazdaspeed3 front brake pads - B3YF3323Z
mazdaspeed3 front rotor - B37F3325XA
mazdaspeed3 rear brake pads - C2Y32648ZA
mazdaspeed3 rear rotor - C25Y26251B
mazdaspeed6 front brake pads - GPYA3323ZG
mazdaspeed6 front rotor - G31Y3325XA
mazdaspeed6 rear brake pads - GPYB2648Z and apparently you need this as well - GPYB2649Z
mazdaspeed6 rear rotor - G31Y26251

suspension
mazdaspeed3 front sway bar - B37F34151
mazdaspeed3 front end links - B37F34170A
nuts for front end links - 999401001
mazdaspeed3 rear sway bar - B37F28151
mazdaspeed3 rear end links - B37F28170A
nuts for rear end links - 9YB101005

gaskets
head gasket - L3K910271C
turbo to manifold - L3K913710
turbo manifold to head - L3K913460
downpipe to turbo - L3F213490
intake manifold gasket to head - L3K913111
throttle body gasket - L3K913655
donut gasket - L3A140581
bpv to cold pipe oring diamond shaped "gasket" - L3K920255

fasteners
turbo and manifold studs - L33E13146A
nuts for studs - JE1040355

miscellaneous

subed

philly you suck
but this thread might win.

guys, if there's something you want on here, let me know. i can probably find the info

philly I need the number for the plastic fastener that holds the side skirts... Its white.

I ran over a semi tire a few weeks ago and it ripped part of my side skirt off, its currently dangling. Looks normal, but its barely hanging on lol

you talking about something in this pic?

http://i44.tinypic.com/166ddmp.png

yea that looks like it. They are little plastic grommets that hold that side skirt on

scatt, those clips are - B09251833
i'm not sure if that's what you mean though. perhaps get a pic...or honestly take it to the dealer

whats the part # for the missing half of your brain philly??

nator?

i organized these lists a bit more. does anyone else have part numbers that are commonly used?
things that often need to be replaced?
or things that you'll need for particular mods?

philly anyway you could get the part number for the light bulb behind the fan dial on the speed6?

my source is down. fuck...

Link failed

yeah, shit is dead. i guess i can't use that shit no more. shit was dope

anybody else know of a good site to find part numbers?

MY all data site gives part numbers if you need any.

cool. thanks. next time i do i'll let you know darky.

all data ftw

bump for stock turbo oil drain line part number.

EDIT: found some good stuff...
oil drain/return line (one that us ATP turbo guys were forced to cut) = 14-290
the gaskets for the two-bolt flange on top = 14-293 (accompanying bolt x2 = 9kf00-2127L)
and the gasket for the bottom = 14-264D (accompanying bolt x2 = 9kf00-2147L

im kinda new to this but uhmm, u got the number for the speed6 wheels?

very useful thanks for the information in this post i was able to find the part i needed with ease.

speed6 wheels - 9965117080

dane, the first part you listed is actually - L33E14290 - oil drain/return line
gasket - L3K914293 and bolt you've done correclty - 9XF002127L
gasket for the bottom - L3K914264

i know this is really late, but i believe the pn is - GJ6G61C95

http://allmazda.net/epcimg/2G6/2G68021.GIF


Here's the whole rear diff setup for the speed6

» 17122 PLUG,MAGNET
» 17180 BEARING
» 26060 BREATHER
» 27012 WASHER
» 27018 SEAL,OIL
» 27020 FLANGE,COMPANION
» 27020A DRIVING & DIFF.
» 27030 NUT,LOCK
» 27100 DRIVING & DIFF.
» 27110 GEAR SET,FINAL
» 27141 BEARING,PINION
» 27144 SPACER
» 27150 CARRIER,DIFFERENTIAL
» 27171 PIECE,DISTANCE
» 27200 DIFFERENTIAL
» 27222A CUP,BEARING-DIFFERENTIAL
» 27235 BOLT,RING GEAR
» 27238 SEAL,OIL
» 27305 BEARING
» 27320A COVER,REAR
» 27351 CONE,BEARING
» 27355 SHIM,ADJUST
» 27401 SPACER
» 27431 SPACER
» 27583A SPACER
» 27604 BOLT
» 27681A CASE,COUPLING
» 27691A SHAFT,OUTPUT
» 2797X COUPLING
» 2798XA SENSOR
» 90781 BOLT & WASHER
» 90901 NUT
» 99201 WASHER
» 99305 PLUG
» 99571 RING,SNAP
» 99601 BOLT
» 99601 BOLT
» 99601 BOLT

those aren't the pns...but thank you

Re: oem part numbers


Then what r the pns? Lol, sorry.


Sent from my iPhone using Tapatalk

http://www.carfieldenterprise.com/li...DSC00795ed.jpg

MPS emblem . rear in chrome BR6C-51-721

Do any of these part numbers cross reff with Ford part #'s? Especially the block and other transaxle parts?

no clue unfortunately. i don't have access or haven't found a ford site with pns

when you click on the list on the right, you will see the actual part number.

part number for the stupid diamond shaped gasket for the bpv to cold pipe???

L3K920255

Where is the best place to order these brake pads? I'm about to have to replace them.

http://www.trademotion.com/partlocat...?siteid=214264
Mazda Parts - Discount Mazda Parts & Accessories below wholesale

Thanks phillyb. Good to be back, I take it that since you're still posting your car hasn't died yet...

hahahaha. alive and well. though it's leaking coolant, cylinder 2 misfires all the fucking time.

Wow... this thread is great...

Thx phillyb!

haha, well this website will save me a bit, its still gonna be 380 before labor if I gotta replace pads and disks though. Oh well. and man philly, why can't you get that thing to just run normal

lol dustin, this thread has been here for almost a year...you're just seeing it?

could always just do it yourself.
lol.
and dude, it's one thing after the next. when i replace plugs and fix leak, i'll need to replace my meth pump...it's leaking.
and then when i fix that, something else will pop up.

Finally had a reason to look :D
